Vex

Fast hybrid structural + semantic code search. Vector + index.

Why Vex? · How It Compares · Installation · Quick Start · Commands · Configuration · How Search Works · Benchmarks · Supported Languages · Integration · Testing · Architecture

$ vex check "TelemetryProcessor"           # 4ms — does it exist? where? (exact name)
$ vex show "TelemetryProcessor"            # extract the class body (not the whole file)
$ vex usages "Config" --strict             # who references this symbol? (binder-resolved, no noise)
$ vex callers "process_event"              # who calls this function? (~4ms; covers module-scope + Python/Java decorators)
$ vex implementations "BaseService"        # who extends/implements this?
$ vex search "timeout retry"               # fuzzy / multi-word — BM25 finds rare body terms
$ vex search "handle alert" --semantic     # find by meaning, not just name
$ vex pattern 'fn $NAME($$$) -> Result' --lang rust    # AST pattern matching (like ast-grep)
$ vex similar "PaymentService"             # semantically close symbols
$ vex duplicates --threshold 0.95          # near-duplicate pairs
$ vex bundle --mode symbol --symbol Foo    # body + callers + callees + similar in 1 call

Pick the right tool: vex check for "does Foo exist?", vex search for "find me something about retries". search is a ranked blend — it surfaces neighbors (callers / imports) when no symbol literally matches, which is great for exploration and wrong for exact-name lookup. v1.15.0 prints a stderr hint when an identifier-shaped search returns 0 FST hits.

Why Vex?

• ~4-5ms search after indexing — FST-based O(query_len) lookup, not O(symbols); constant regardless of project size. Requires a pre-built index. Indexing is a one-time cost (hundreds of ms on typical projects) and builds more than a plain text index — FST + BM25 + call graph + type-hierarchy + trigram skip-index — so it trades a slower build for far cheaper, richer queries (see Benchmarks)
• 3-channel hybrid search — structural FST (names) + BM25 (rare body terms) + semantic HNSW (meaning), fused via Reciprocal Rank Fusion. Find symbols when you don't know the exact name AND when generic semantic-only search would be too noisy
• Persistent call graph — vex callers/vex callees read from a persistent index built at index time (~4ms), not a live tree-sitter scan (seconds): callers is a name-keyed FST, callees is a dense CSR index (v9+). Module-scope expressions are reported via synthetic <module:path> callers (Phase 14.1); Python + Java function/method decorators (Phase 14.2), Kotlin annotations + C# method/constructor attributes (Phase 14.2.2), and TypeScript method decorators + Rust outer attributes (Phase 14.2.1) emit forward edges to their targets. Class-level decorators remain invisible — see docs/LIMITATIONS.md
• Pluggable embedder — Embedder trait + registry; swap MiniLM-L6-v2 for future code-specific models (BGE, CodeBERT) without touching call sites
• Token-efficient — compact output saves typically 6x fewer tokens than grep on average lookups (up to 217x on minified JS/CSS); vex show extracts just the symbol body instead of the whole file
• 19 languages indexed via tree-sitter, with three coverage tiers: type-aware --strict usages on 8 binder languages (Rust / TypeScript / Python / C# / C++ / Go / Java / Kotlin); indexed pattern prefilter on 15 T1+T2a languages; baseline structural + semantic search on all 19 (see Supported Languages for the matrix)
• Single binary, zero config — no LSP servers, no databases, no Docker. Just vex index && vex check Foo

What Vex isn't

vex is a static-analysis indexing tool, not a language server. Set expectations honestly:

• Not an LSP replacement. No go-to-definition into third-party packages, no rename refactoring, no type-checking, no hover docs. For those, keep your LSP.
• vex search is a ranked blend, not an exact-name lookup. Structural FST + BM25 + semantic fused via RRF return relevance-ordered results — when no symbol literally named Foo lives in the index (imported from a dependency, deleted, typo), BM25 may surface callers / imports as if they were the definition. For exact-symbol questions ("does it exist?", "show me the body", "who calls it?") use vex check Foo / vex show Foo / vex usages Foo --strict — they bypass the ranker. v1.15.0 prints a one-line stderr hint when an identifier-shaped query gets zero FST hits.
• No dynamic-dispatch visibility. Decorator routing (@router.get("/path")), string-resolved factories (uvicorn.run("main:app")), reflection (getattr(obj, name)()), and macro-expanded references are all invisible to every vex command. vex grep '\bname\b' is the textual escape hatch.
• vex callers has uneven coverage outside function scope. Module-level expressions like app = create_app() are reported via synthetic <module:path> callers (Phase 14.1). Python + Java function/method decorators (Phase 14.2), Kotlin annotations + C# method/constructor attributes (Phase 14.2.2), and TypeScript method decorators + Rust outer attributes on fns/methods (Phase 14.2.1) emit forward edges — vex callers GetMapping lists every Spring handler, vex callers HttpGet every ASP.NET action, vex callers test every #[tokio::test]. Class-level decorators (14.6) remain on the roadmap.
• vex usages quality varies by language. 8 binder-supported languages get refactor-grade --strict refs; the other 11 use an identifier scanner with a higher false-positive rate.

See docs/LIMITATIONS.md for the full coverage matrix, concrete repros, and recommended workarounds per query type. Read it before evaluating vex on a Python/FastAPI/Django codebase — the framework patterns are the most-flagged gaps.

How It Compares

	vex	ripgrep	ast-index	ast-grep	Serena
What it searches	Symbol definitions	All text	Symbol definitions	AST patterns	Symbols (via LSP)
Requires indexing?	Yes (~0.3-1s)	No	Yes (faster build)	No	No
Search speed	~4-5ms (pre-built FST, constant)	scales w/ corpus (~8ms small → 100ms+ large)	~8-12ms (SQLite)	~30ms (scan)	LSP-dependent
Semantic search	HNSW + embeddings	--	--	--	--
Pattern matching	fn $NAME($$$)	regex only	--	fn $NAME($$$)	regex only
Index size	~1.5-2x smaller than ast-index	no index	SQLite + FTS5	no index	no index
Token efficiency	6-217x fewer than rg	baseline	~3x fewer than rg	N/A	N/A
Symbol body extraction	vex show	--	--	--	--
Languages	19	any	10+	10+	40+ (LSP)
Refactoring	--	--	--	--	rename, move, inline
Runtime deps	none	none	none	none	Python + LSP

Note: vex search speed assumes a pre-built index. Ripgrep and ast-grep require no upfront indexing and work immediately on any directory. The tradeoff is amortized: if you search the same codebase many times (typical in agent workflows), the one-time indexing cost pays for itself.

Best for: fast symbol search in AI agent workflows where token efficiency matters. Not a replacement for LSP-based tools (no refactoring, no go-to-definition in dependencies).

Installation

# Install script (macOS arm64, Linux x86_64): vex + vex-mcp into ~/.local/bin
curl -fsSL https://raw.githubusercontent.com/tenatarika/vex/main/install.sh | sh

# Homebrew (macOS/Linux)
brew tap tenatarika/tap
brew install vex

# cargo-binstall: prebuilt release binaries, no compiler needed
cargo binstall vex-search                # → ~/.cargo/bin/vex
cargo binstall vex-search-mcp            # → ~/.cargo/bin/vex-mcp (MCP server)

# crates.io (compiles from source; the crate is `vex-search`, the binary is `vex`)
cargo install vex-search --locked        # → ~/.cargo/bin/vex
cargo install vex-search-mcp --locked    # → ~/.cargo/bin/vex-mcp (MCP server)

# From source (any platform with a Rust toolchain)
git clone https://github.com/tenatarika/vex.git
cd vex
cargo build --release
cp target/release/vex ~/.local/bin/

The install script takes VEX_VERSION=1.27.4 to pin a release, VEX_INSTALL_DIR to install elsewhere and VEX_NO_MCP=1 to skip vex-mcp. On other platforms, musl or glibc older than 2.34 it stops and points to a source build. cargo binstall uses the same release archives where they exist and builds from source elsewhere; on Windows it installs vex.exe without the archive's DirectML.dll, so GPU indexing falls back to CPU.

What cargo install vex-search (and any source build) needs:

• Network at build time: the build downloads a prebuilt ONNX Runtime. Prebuilts exist only for aarch64-apple-darwin, x86_64/aarch64-unknown-linux-gnu and x86_64/aarch64-pc-windows-msvc; on any other target (Intel macOS, musl, …) point ORT_LIB_LOCATION at a local ONNX Runtime build.
• A C/C++ toolchain (Xcode Command Line Tools, build-essential, or MSVC Build Tools) for the tree-sitter grammars. GCC must be 12 or newer: GCC 11 (the default on Ubuntu 22.04) can't compile the bundled numkong vector kernels. Install gcc-12 g++-12 and build with CC=gcc-12 CXX=g++-12 cargo install vex-search --locked.
• Linux: libssl-dev and pkg-config (Fedora: openssl-devel). The HTTP stack links OpenSSL through native-tls.
• The first vex index --semantic downloads the ~86 MB embedding model; structural search needs no download.
• vex-search-mcp only installs the MCP server. It runs the vex CLI, so install vex-search too and keep vex on PATH, or set VEX_BIN to its full path.

Linux

Pre-built vex ships in every GitHub Release for x86_64-unknown-linux-gnu. It needs glibc 2.34 or newer (Ubuntu 22.04+, Debian 12+, RHEL / Rocky / AlmaLinux 9+); on older systems build from source:

curl -fsSL https://raw.githubusercontent.com/tenatarika/vex/main/install.sh | sh
# or by hand:
curl -L https://github.com/tenatarika/vex/releases/latest/download/vex-x86_64-unknown-linux-gnu.tar.gz | tar -xz
mv vex ~/.local/bin/      # or: sudo mv vex /usr/local/bin/
vex --version

Built on the ubuntu-22.04 GitHub runner (glibc-linked, libstdc++ linked in). For older glibc distros, musl-based distros (Alpine, NixOS without nix-ld), or aarch64 Linux (Graviton, Pi 5, Ampere) — build from source via cargo build --release.

Windows

Pre-built vex.exe ships in every GitHub Release.

1. Download vex-x86_64-pc-windows-msvc.tar.gz from the latest release
2. Extract vex.exe somewhere stable (e.g. C:\Users\<you>\bin\) — tar -xzf vex-x86_64-pc-windows-msvc.tar.gz from a recent PowerShell, or 7-Zip / WinRAR via right-click. Security note: vex.exe loads the bundled DirectML.dll from its own folder, so on a multi-user machine or shared drive prefer a directory other users can't write to (e.g. C:\Program Files\vex\ — with the trade-off that vex self-update then needs an elevated shell). See GPU_SUPPORT.md §6.
3. Add that folder to PATH (System Properties → Environment Variables → edit Path → add the folder)
4. Open a fresh terminal and run vex --version

To update, run vex self-update — it fetches the latest release, picks the right archive for your platform, verifies its signature, and replaces the binary in-place. On Windows it also installs/refreshes the bundled DirectML.dll sidecar (skipped when byte-identical; re-installed if an older self-update dropped it — updaters up to v1.16.0 extracted only the binary). Same command works on macOS and Linux too.

GPU acceleration is built into the prebuilt binaries — Windows ships with DirectML (any DX12 GPU, driver-only; the redist DirectML.dll is bundled in the archive) and macOS arm64 with CoreML. NVIDIA CUDA is a source-build opt-in. Run vex gpu to check, and see GPU Acceleration.

Quick Start

# Index a project (structural only — fast)
vex index --path /path/to/project

# Index with semantic embeddings (slower first time, downloads 86 MB model)
vex index --path /path/to/project --semantic

# Exact-name lookup (does this symbol exist?)
vex check "PaymentService"

# Extract a symbol's body (no whole-file read)
vex show "PaymentService"

# Fuzzy / multi-word search (returns ranked neighbors when no symbol matches)
vex search "payment processing" --semantic

# Find all usages of a symbol (--strict drops string-literal / comment / wrong-scope noise)
vex usages "IndexReader" --strict

# File structure outline
vex outline src/main.rs

# Find implementations of a trait/interface
vex implementations "Iterator"

# Callgraph: who calls / is called by a function (fast path via persistent index)
vex callers "process_event"
vex callees "process_event"

# Multi-hop call graph (v1.7)
vex paths "main" "process_event"          # all caller chains from main → process_event
vex reachable "process_event"             # everything that transitively reaches it
vex tests-for "process_event"             # tests covering process_event (path globs + name heuristic; framework label per row)

# Symbol-level diff against a branch (v1.7)
vex diff --base main                      # what symbols did this branch change?

# Historical view of a symbol — every commit that touched it (v1.15.0; v1.16.0 expanded)
vex index --history                       # build the persistent history sidecar once
vex history "PaymentService"              # ~10ms — every version reachable from HEAD
vex history "PaymentService" --diff       # unified diffs between consecutive versions
vex history "Foo" --since 2026-01-01 --author alice --kind function
vex history "deleted_symbol" --exact-presence    # exact commit set where each blob lived (revert-aware)

# Semantic similarity by existing symbol — explain what's actually similar (v1.7)
vex similar "PaymentService" --limit 5 --min-score 0.7 --explain

# Near-duplicate pairs with reasoning (v1.7)
vex duplicates --min-score 0.95 --min-body-lines 5 --explain

# Search with per-call scope + metadata filters (v1.7)
vex search "Repository" --include 'src/**' --exclude '**/*.gen.*' --visibility public --async-only

# Why did the search return these results? (v1.7)
vex search "Foo" --why 2>trace.json

# Bundle: 4 round-trips → 1 envelope (v1.9, Phase 13.2)
vex bundle --mode symbol --symbol PaymentService          # body + callers + callees + similar
vex bundle --mode pr-impact --base origin/main            # changed symbols + transitive callers + tests
vex bundle --mode project --top-n 30                      # top-N by reverse call-graph indegree

# Diff-context filters on every search-shaped command (v1.9, Phase 13.7-D3)
vex search "Repository" --since-branched                  # only files changed since branching from main
vex usages "Config" --since HEAD~3                        # refs within the last 3 commits
vex callers "Foo" --changed-only                          # working-tree changes only

# Extract just a symbol's body — replaces Read for a specific function/class
vex show "PaymentService"                                 # full body of the class / fn
vex show "Foo" "Bar" "Baz"                                # multiple symbols in one call

# Smart show truncation for token efficiency (v1.9, Phase 13.3)
vex show "BigClass" --signature-only                      # just the signature line
vex show "PaymentService" --head 20                       # first 20 lines of the body
vex show "Foo" --no-body                                  # signature + docstring, no body

# Ranking-eval harness — CI regression guard (v1.9, Phase 13.12)
vex eval --bench benches/ranking_golden/queries.toml      # nDCG@10 / recall@10 / MRR per query
vex eval --min-ndcg 0.85                                  # fail if mean nDCG drops below threshold

# Capability discovery for MCP clients (v1.9, Phase 13.0)
vex capabilities                                          # JSON: protocol_version, signals, bundle_modes, …

# Fast existence check
vex check "Foo" "Bar" "Baz"

# Incremental update (re-parses only changed files, reuses unchanged from index)
vex update

# Watch mode (re-indexes on file changes)
vex watch

# Multi-repo: treat a set of sibling repos as one workspace (v1.22.0)
vex index --workspace                     # build every member of .vex-workspace.toml
vex search "RetryPolicy" --workspace      # fan out, results grouped by repo
vex usages Config --strict --workspace    # cross-repo strict refs (v7+ index)
vex watch --workspace                     # keep every member incrementally fresh

# Show index stats
vex status

# GPU doctor — is the compiled EP actually engaging on this machine? (v1.16.0)
vex gpu                                   # probes the compiled-in EP with strict registration
vex gpu cuda                              # narrow to one EP
vex gpu --enable                          # persist working device to VEX_DEVICE

# Shell completions
vex completions zsh > ~/.zfunc/_vex

Commands

Command	Description
vex index [--path .] [--semantic] [--embedder ID] [--history [--history-depth N]] [--no-clusters] [--no-pattern-index] [--drop-semantic] [--gpu/--device]	Build full index. --semantic generates embeddings + HNSW + BM25. --embedder selects embedding model (default minilm-l6-v2). --no-clusters skips symbol clustering (v9). --no-pattern-index skips pattern skeleton section (v6). --drop-semantic (with --no-semantic) deletes the on-disk semantic artifacts (HNSW + hash index + embedder cache). --gpu/--device controls GPU acceleration (GPU-enabled builds). --history (v1.15.0) builds the Phase 14.8 persistent history-symbol section (<index_dir>/index.git_history) so vex history <Symbol> runs in FST-lookup time. --history-depth N caps the walk at N newest commits (global, not per-file).
vex search <query> [--semantic] [--no-bm25] [--limit N] [--kind def,fn,…] [--visibility V] [--async-only] [--code-only] [--exclude-generated] [--why]	Hybrid search: structural + BM25 + semantic (when --semantic). 3-way RRF fusion. Multi-value --kind (canonical names + meta-selectors def/comment/test/ref). Metadata post-filters narrow by signature keywords. v1.20.0 (D4): per-result signals block now carries raw bm25_score + semantic_cosine alongside the rank ordinals so agents can read absolute relevance quality; _meta.vex.dev/semantic_channel reports "not_requested" / "index_lacks_vectors" when the semantic channel didn't run; --code-only drops hits in *.md/*.markdown/*.txt/*.rst/*.adoc for code-intent queries; --exclude-generated drops machine-generated files (protobuf stubs, sqlc output, bindgen bindings, ORM schemas), recognised from the generator's header banner — useful on repos that check in generated code, and a heuristic that under-reports rather than hiding hand-written code (see docs/LIMITATIONS.md §10.2). --why appends a JSON trace to stderr. v1.15.0 search-drift hint: when the query is identifier-shaped (compile_query, Foo, _internal) and the structural FST finds zero matches, vex prints a one-line stderr hint pointing at vex check / vex show / vex usages --strict — the typical "imported-from-dependency" case where BM25 would otherwise surface callers as if they were the definition. See docs/COOKBOOK.md FAQ.
vex show <symbol> [--limit N] [--context N] [--kind fn] [--visibility V] [--async-only] [--signature-only | --head N | --no-body]	Extract symbol body from source (saves tokens vs full file read). Same metadata + kind filters as search. Smart truncation flags (since v1.9) — --signature-only keeps only the declaration line, --head N keeps the first N body lines, --no-body returns signature + docstring only. Mutually exclusive.
vex similar <name> [--limit N] [--min-score T] [--explain]	Find symbols semantically close to an existing one (HNSW nearest neighbors). --explain adds identifier-Jaccard + truncated unified diff per match. --min-score is an alias for --threshold.
vex duplicates [--min-score T] [--min-body-lines N] [--explain]	List near-duplicate symbol pairs by embedding similarity. --explain shows what's actually different between the bodies.
vex usages <name> [--limit N] [--strict] [--include-self] [--include-docs]	Find all references/usages of a symbol. Non-strict path = FST lookup; v1.20.0 strips the row at the symbol's own definition line and *.md/*.markdown/*.txt/*.rst/*.adoc matches by default — use --include-self / --include-docs to restore the pre-v1.20 wide-net behaviour. --strict reads binder-resolved refs from the v5 reference_edges section (Rust / TypeScript / Python / C# / C++ / Go / Java / Kotlin).
vex impact <name> [--depth N] [--exclude-docs]	One-call delete-safety blast-radius report (since v1.20.0). Composes four reference channels — strict refs (binder-resolved), FST refs, grep \b<Name>\b, and direct call-graph callers — into a single verdict (safe / unsafe / uncertain) with a per-channel evidence sample. Use this BEFORE proposing to delete or rename a symbol; one call replaces the manual usages→grep→callers dance. Verdict rule: unsafe if strict refs OR call-graph callers report >0 (binder/graph confirms real usage); uncertain if only text channels hit (likely string-dispatch / comment / decorator); safe only when every channel returns zero. --depth N (1..16) walks the call graph backward to surface indirect callers at depth ≥ 2; --exclude-docs drops prose-format mentions (*.md/*.txt/…) so a CHANGELOG-only symbol flips to safe.
vex pattern '<pat>' --lang <lang> [--why]	AST pattern matching with metavariables ($NAME, $_, $$$, plus the v6 named multi-line forms $$$BODY / $$ARGS). Repeated metavars enforce back-references. Space-flanked && / `
vex outline <file> [--kind fn]	Show file structure, optionally filter by symbol kind.
vex implementations <name>	Find types that extend/implement a base class, trait, or interface (incl. generic-parameterised: class Foo : Repository<T>). Index-backed (v8 hierarchy section) — a find_hierarchy_edges_by_symbol FST + binary-search lookup, falling back to the original live tree-sitter walk only when the index lacks the section. Bench (benches/hierarchy.rs, 150 implementers): ~265 ns index-backed vs ~22.7 ms live walk — ~85,000× faster.
vex subtypes <name> [--depth N]	Transitive-down closure over extends/implements edges (direct children, grandchildren, …), each row labelled with its BFS hop depth. Excludes Uses (trait/mixin composition) from the walk — mixing in a trait doesn't make you a subtype of everything the trait itself composes. Index-only, no live-walk fallback (requires an index with the v8 hierarchy section). Bench: ~1.1 µs for a 20-hop transitive chain.
vex modules [SYMBOL] [--min-size N] [--members N] [--sort size|cohesion]	De-facto modules: clusters of symbols that call/reference each other, computed on vex index (deterministic Leiden-CPM over call + ref + hierarchy edges; requires v9 index). Without SYMBOL, lists clusters with a label (dominant path prefix), size, cohesion and hub symbols; with SYMBOL, shows that symbol's cluster and members. --include/--exclude/--exclude-tests scope the members. Exits 1 with an empty_reason when the index has no clusters (pre-v9 index, --no-clusters). Hidden alias: vex clusters. See Symbol clusters.
vex callers <name>	Direct callers of a function (fast path via persistent call graph; falls back to live tree-sitter scan when the index is missing).
vex callees <name>	Direct callees of a function (same fast path).
vex paths <from> <to> [--max-hops N]	Enumerate all caller chains from from to to over the persistent call graph. Bounded DFS with cycle prevention; default --max-hops 6.
vex reachable <target> [--max-hops N] [--limit N]	Transitive set of symbols whose callees reach target, with the BFS depth labelled per row. Blast-radius analysis.
vex tests-for <target> [--max-hops N] [--limit N] [--test-pattern <glob>] [--include-fixtures]	Test functions that transitively cover <target>. Post-filter on top of vex reachable: walks the call graph backwards, keeps rows under recognized test-path globs (Rust / Python / TS-JS / Go / Java / Kotlin / C# / C++), stamps each row with a framework label (pytest, jest, go-test, …) so an agent can pick the right runner. --test-pattern <glob> (repeatable) REPLACES the default set; --include-fixtures admits one forward hop of test-path helpers in addition to weakening the name-prefix filter.
vex diff --base <rev> [--limit N]	Symbol-level diff between an arbitrary git revision and the working tree: added / removed / moved-within-file / body-changed entries. git diff --no-renames semantics so a git mv surfaces both halves.
vex bundle --mode <symbol|pr-impact|project> [...]	Unified multi-source bundle (since v1.9) — replaces 4 round-trips (show → callers → callees → similar) with one. --mode symbol --symbol Foo returns body + callers + callees + semantic similar. --mode pr-impact --base origin/main returns changed symbols + transitive callers (depth=2 default) + tests. --mode project [--top-n 30] returns top-N by reverse call-graph indegree (experimental — see docs/MCP-SCHEMA.md#bundle-modes-v19 for the response shape and mode_hints per-mode keys). Always emits the v1 envelope { protocol_version, capabilities, _meta, results }.
vex check <name> [name...]	Fast existence check — which symbols exist in the index?
vex grep <pattern> [--filter-path path/]	Regex content search (no index needed).
vex update [--path .] [--semantic] [--embedder ID] [--history | --no-history]	Incremental update — re-parse only changed files, reuse unchanged symbols from existing index. --history (v1.15.0) is sticky via the manifest: if the prior build had a history section, vex update keeps it fresh via a 3-branch walker (fast-path skip on no-new-commits, incremental on linear history, full rebuild on force-push). --no-history drops the section + nulls the manifest fields.
vex watch [--path .] [--semantic] [--embedder ID]	Watch filesystem, auto re-index on changes.
vex status [--path .] [--coverage]	Show index stats: symbol count, size, embeddings, call graph, BM25, GPU support. --coverage adds a file-coverage diagnostic: indexed files per language, files discovered but not indexed (with reason), and manifest entries missing on disk.
vex gpu [device] [--enable]	Diagnose GPU acceleration: prints the execution provider compiled into this binary and actively probes whether it engages on this machine (a silent CPU fallback shows as FAILED with setup remediation). vex gpu cuda probes one EP; --enable persists the working device to VEX_DEVICE (user env via setx on Windows; prints the export line to add on macOS/Linux) when a GPU engages. See GPU Acceleration.
vex completions <shell>	Generate shell completions (bash, zsh, fish).
vex init [--agents-md] [--agents-md-only]	Create a default .vex.toml in the current directory. --agents-md also writes AGENTS.md for agent tools. --agents-md-only writes only AGENTS.md (skip .vex.toml).
vex mcp <install|uninstall|list> --agent <id|all> [--dry-run] [--force]	Manage vex-mcp server entry in coding agent configs. install registers idempotently; uninstall removes; list shows current entries. --agent all fans out across all supported agents. --dry-run previews without writing. --force overwrites existing entries.
vex capabilities	Print the machine-readable capability matrix (since v1.9): protocol_version, signals, why, scope_filters, metadata_filters, empty_reason, bundle_modes, auto_update, async_update, history_diff, structured_result_kind, result_completeness, symbol_clusters. MCP / agent clients probe this once at startup instead of re-reading help text.
vex eval [--bench PATH] [--min-ndcg F] [--json]	Run the ranking-evaluation harness against a hand-curated golden query set (since v1.9); reports nDCG@10 / recall@10 / MRR per query and aggregated. CI regression guard — fails when mean nDCG drops below --min-ndcg. Default golden set: benches/ranking_golden/queries.toml.
vex history <Symbol> [--depth N] [--limit N] [--branch REV] [--no-index] [--since YYYY-MM-DD] [--until YYYY-MM-DD] [--author SUBSTR] [--kind KIND] [--diff] [--exact-presence]	NEW (v1.15.0); expanded in v1.16.0 (Phase 14.9). Every historical version of a symbol reachable from a chosen tip. With vex index --history previously run, queries hit a persistent FST sidecar (~10 ms — 1640× faster on tokio-scale repos than the walker). Without the section, shells out to git log (~seconds). Indexed mode also finds symbols whose name has been deleted from HEAD — the walker can't. v1.16.0 additions: date/author/kind filters (lex YYYY-MM-DD compare); --diff renders unified diffs between consecutive versions (only signature lines change shape, head of group keeps full sig); --exact-presence enumerates the exact commit set where each entry's blob lived (revert-aware, capped by --exact-presence-max-commits); prefix-FST fallback on the indexed path for identifier-shaped queries length ≥ 3; JSON envelope ported to standard ResponseEnvelope shape (BREAKING for MCP consumers reading results.items[]). See docs/HISTORY-INDEX.md for the full pipeline + cookbook.
vex self-update [--check] [--yes]	Update vex to the latest GitHub release. Replaces the running binary in place. Works on Linux, macOS, and Windows.

Per-query filters (every search-shaped command)

All search-shaped commands accept scope filters. Specific filters vary by command:

• --include <glob> / --exclude <glob> (repeatable, gitignore syntax) — per-call path scoping that doesn't require re-indexing. --exclude wins over --include. Example: vex search Foo --include 'src/**' --exclude '**/*.gen.*'. --exclude-tests (MCP: exclude_tests: true) drops test files (tests/, *_test.*, test_*.py, *.spec.ts, __tests__/, tests.rs, … — the same set as vex tests-for); it composes with --include/--exclude, is recorded in the --why trace, and is applied by every command that takes the scope flags (search, usages, callers/callees, impact, grep, show, pattern, implementations/subtypes, similar/duplicates, modules, paths, reachable, diff, bundle pr-impact — there it filters the changed files and the transitive-caller/test rows; bundle symbol/project modes ignore all scope filters). vex tests-for rejects --exclude-tests (exit 2): it lists test functions, so the flag would always return nothing. Path-based only: Rust unit tests inside a #[cfg(test)] mod tests block of a non-test file are not excluded.
• --filter-path <substring> (alias --filter) — path-substring filter on search, show, usages, grep, similar, duplicates. Composes AND with the globs.

vex search / vex show additionally accept:

• --visibility <public|private|protected|internal> — keep only symbols whose signature carries the explicit keyword. Defaults aren't inferred (bare Rust fn foo() does NOT match --visibility private).
• --async-only / --no-async — keep or exclude async / Kotlin-suspend symbols.
• --static-only, --sealed-only — restrict to static class members or sealed (or Java-final) types.

Reasoning flags

• vex search --why prints a JSON trace to stderr (the result list stays on stdout): normalized_query, per-channel hit counts (FST / BM25 / semantic), fallbacks engaged (fuzzy), and the active filter snapshot.
• vex pattern --why prints a JSON ScanTrace to stderr after the result list: mode (indexed / live_scan), root_kind_inferred, candidate_files / total_files, and fallback_reason when the indexed prefilter was skipped (no-index, no-skeleton-section, empty-section, grammar-drift, partial-section, index-open-error). MCP callers see the same JSON under _meta.why.
• vex similar --explain / vex duplicates --explain add a jaccard overlap score plus a truncated unified diff between the two bodies, so you can decide whether two semantically-clustered symbols are actually duplicates before acting.

Multi-repo workspaces (--workspace) — v1.22.0

Declare a set of sibling repos in a .vex-workspace.toml and run any command with --workspace to fan out across all of them, grouped by repo:

# .vex-workspace.toml (at the directory that contains the repos)
members = ["./api", "./worker", "./shared-lib"]

vex index --workspace                   # build every member into its own per-repo index
vex update --workspace                  # incremental refresh, per-repo changed/deleted counts
vex usages Config --strict --workspace  # cross-repo strict refs, grouped by repo

• --workspace is accepted by index, update, search, grep, check, usages, impact, callers, callees, reachable, modules, and watch. Each member keeps its own .vex.toml (excludes / embedder / sections / cache).
• Reference and call-graph resolution is per-repo by default. The one exception is vex usages <name> --strict --workspace, which resolves a reference in repo B to a symbol defined in repo A via a gtags-style name fallback (rendered as a name-resolved sub-tier). Requires v7+ index — re-run vex index after upgrading.
• A member missing a capability (--strict on an old index, a call graph for reachable) is reported unavailable for that repo instead of aborting the whole fan-out. --workspace conflicts with --why. See docs/MULTIREPO.md and LIMITATIONS §7.

Configuration

Create a .vex.toml in your project root to customize vex behavior:

vex init  # generates .vex.toml with commented defaults

# .vex.toml

# Glob patterns to exclude from indexing (gitignore syntax, on top of .gitignore)
exclude = [
    "vendor/**",
    "node_modules/**",
    "*.generated.go",
]

# Output format — "compact" (default since v1.10.1; single-line records),
# "text" (verbose multi-line), or "json" (envelope for MCP / tools).
# format = "text"

# Enable semantic embeddings by default
semantic = true

# Automatically update index before search if stale
# auto_update = false

# With auto_update, refresh in the background rather than blocking the query:
# answers come from the index on disk, the response is flagged stale, and the
# rebuild lands for the next query. Trades freshness for latency.
# async_update = false

# GPU device for semantic indexing (GPU-enabled builds only). "auto" uses the
# compiled-in GPU EP when it initializes, else CPU; or "cpu"/"cuda"/"directml"/
# "coreml". `gpu = true/false` is shorthand for auto/cpu. See GPU Acceleration.
# device = "auto"
# gpu = true

# Embedder model: minilm-l6-v2 (default), jina-code, bge-base-en-v1.5,
# bge-large-en-v1.5, mxbai-large. Changing it requires a reindex.
# Set globally across projects with the VEX_EMBEDDER env var (this file wins).
# embedder = "minilm-l6-v2"

# VCS backend for diff-scoping (--since/--since-branched/--changed-only).
# "auto" (default) detects .git/.svn/.arc; "git" | "none" | "arc" | "svn".
# git, arc (Yandex Arc), and svn (Subversion) are all functional backends;
# svn declines --since-branched (no merge-base). "none" disables diff-scoping.
# Overridden by the --vcs flag and the $VEX_VCS env var. See docs/VCS-BACKENDS.md.
# vcs = "auto"

CLI flags always override config values. Use --no-semantic to explicitly disable semantic mode when the config enables it. The VEX_DEVICE and VEX_EMBEDDER environment variables act as global defaults across all projects (lowest precedence, below .vex.toml) — see GPU Acceleration.

Keeping config out of the repo

Don't want a .vex.toml inside the repository (can't .gitignore it, shared checkout, etc.)? vex never creates one on its own — only vex init writes it — and you have two ways to keep config external:

• --config <path> / $VEX_CONFIG — point vex at a config file anywhere on disk. It replaces the in-repo lookup entirely, so the repo stays clean:

  vex --config ~/vex/this-repo.toml search Foo
  export VEX_CONFIG=~/vex/this-repo.toml   # or set it once per shell

  --config beats $VEX_CONFIG; a missing/invalid path is a hard error (vex won't silently fall back). Relative paths inside that file resolve against the file's own directory.
• A parent directory — config lookup walks up from the project to the filesystem root, so a .vex.toml placed in any ancestor (e.g. ~/work/.vex.toml, or ~/.vex.toml for a machine-wide default) is picked up for every repo beneath it, with none living in the repos themselves.

The index itself is never written into the repo — it lives in the cache dir (--cache-dir / $VEX_CACHE_DIR / platform cache), so a clean repo is just a matter of config placement.

Staleness Detection

Vex detects when the index is stale and warns before search:

$ vex search "Config"
Warning: index may be stale (HEAD changed). Run `vex update`.

How it works: on every search, vex compares the git HEAD stored at index time with the current HEAD (~0.1ms, single git rev-parse). If HEAD changed → stale. For non-git repos, falls back to mtime comparison — and since v1.11 (H11), when mtime fires, vex streams a xxh3_64 content hash of the file and compares it to the manifest. If the hash matches, the touch was cosmetic (git checkout, rustfmt no-op, rsync --times) and the file stays Fresh; only a real content change re-triggers indexing.

Auto-update: skip the warning and update inline:

# Per-command
vex search "Config" --auto-update

# Always (in .vex.toml)
auto_update = true

# Disable staleness check entirely
vex search "Config" --no-stale-check

GPU Acceleration

Semantic indexing (--semantic) can run the embedding model on a GPU — a large win on a full/cold index. On an RTX 3080 over a 28k-symbol C++ module, embedding the default MiniLM model was 51× faster on CUDA and 29× on DirectML vs CPU (full benchmark + design notes in docs/GPU_SUPPORT.md).

Two layers — the binary, and the device:

• Prebuilt binaries bake in a driver-only GPU EP: Windows → DirectML (any DX12 GPU — NVIDIA/AMD/Intel; the redist DirectML.dll is bundled in the archive), macOS arm64 → CoreML. No SDK, no extra install. The Linux prebuilt is CPU-only.
• CUDA is a source-build opt-in (fastest on NVIDIA — ~1.75× DirectML): cargo install --git https://github.com/tenatarika/vex vex-search --features gpu-cuda. Needs the CUDA 12 runtime + cuDNN 9 on PATH (the NVIDIA driver alone is not enough — it ships only nvcuda.dll, not the runtime/cuDNN). Source builds for the others: --features gpu-coreml / gpu-directml.

Selecting the device (vex index / vex update):

• --gpu / --no-gpu — force GPU (Auto) or CPU.
• --device cpu|auto|cuda|directml|coreml — pick a specific execution provider.
• Default is Auto: use the compiled-in EP when it initializes, else silently fall back to CPU. On a CUDA-enabled binary Auto prefers CUDA → DirectML → CoreML; on the standard Windows prebuilt only DirectML is compiled in, so Auto uses DirectML regardless of whether the PC could do CUDA.
• A tiny incremental vex update stays on CPU (the GPU warm-up isn't worth a handful of symbols); cold/large --semantic builds use the GPU.

Is the GPU actually being used? Run vex gpu — it reports the compiled EP and actively probes it, so a silent CPU fallback shows as FAILED with targeted setup remediation. vex gpu cuda probes a single EP; vex gpu --enable persists the working device to VEX_DEVICE (user env via setx on Windows; prints the export line to add on macOS/Linux). A stale VEX_DEVICE pinned to a GPU EP that a later (e.g. CPU-only) build lacks degrades to CPU rather than erroring.

Environment variables

Variable	Effect
VEX_DEVICE	Global default device (cpu/auto/cuda/directml/coreml) for all projects. Below --device/--gpu and .vex.toml in precedence.
VEX_EMBEDDER	Global default embedder id (e.g. jina-code). Below --embedder and .vex.toml. An unknown id falls back to the default embedder with a warning.
VEX_GPU_STRICT=1	Turn ORT's silent CPU fallback into a hard error — proves whether the GPU engaged. (vex gpu requests the same strict mode internally, without touching the environment.)
VEX_GPU_MEM_LIMIT=<bytes>	Advanced: hard cap on the GPU arena VRAM. Set it generously (≥ working set) or it OOMs on long-context batches.
VEX_GPU_ATTN_BUDGET=<n>	Advanced: tune length-aware batch sizing (the count × max_len² budget).

Output Formats

# Compact single-line records — default since v1.10.1 (token-efficient, agent-friendly)
vex search "Foo"

# Verbose multi-line / human-readable
vex search "Foo" --format text

# JSON envelope (for MCP / tool integration; what `vex-mcp` parses)
vex search "Foo" --format json

Pin a different default in .vex.toml via format = "text" if you want the verbose multi-line view at the terminal.

JSON envelope (v1.11.0 — BREAKING for bare-array parsers)

Every --format json subcommand wraps its payload in the Phase 13 envelope. Single shape, easy to detect via protocol_version:

{
  "protocol_version": "v1",
  "capabilities": { /* see `vex capabilities` */ },
  "_meta": { "vex.dev/index_age_ms": 1200, "ttlMs": 30000, "cacheScope": "project" },
  "results": [ /* the actual data, shape depends on the subcommand */ ]
}

Pre-v1.11 only search and bundle returned this envelope; the other subcommands (show, usages, pattern, grep, implementations, callers, callees, paths, reachable, tests-for, check, similar, duplicates, diff, outline, index, update, status, eval) emitted bare arrays / objects. Migration: pre-1.11 jq '.[0].name' or data[0]['name'] now needs jq '.results[0].name' / data['results'][0]['name']. Detect the envelope via response.get('protocol_version') == 'v1' to support both shapes during a rollout window.

How Search Works

Structural Search (default)

Searches by symbol name using an inverted index with CamelCase splitting:

• "PaymentService" — exact match
• "Payment" — prefix match, finds PaymentService, PaymentGateway
• "payment" — case-insensitive, also finds via CamelCase tokens

Semantic Search (--semantic)

Embeds your query with MiniLM-L6-v2 (384-dim vectors) and finds symbols with similar meaning:

• "parse source code files" finds parse_file, extract_refs, parse_file_symbols
• "database storage" finds populate_db, create_10k_db, add_root_persists_to_db
• "find implementations of an interface" finds find_implementations, test_interface_extends

BM25 Channel (auto-on when index has BM25 data)

A classic Okapi BM25 (K1=1.2, B=0.75) over symbol body tokens — identifiers, signatures, docstrings. Closes the gap between "exact name" (structural) and "general meaning" (semantic): finds rare body terms like timeout, retry, singlestore, idempotency_key that aren't part of any symbol name. Since v1.11 (Phase 8.4) body tokens are also extracted from TOML / YAML / HTML / CSS values, so vex search "production endpoint" --semantic can hit a [server] table with endpoint = "https://...". Pass --no-bm25 to disable per-call.

Hybrid Search (3-way RRF)

When the index has all three channels (built with --semantic), vex search fuses structural + BM25 + semantic using Reciprocal Rank Fusion. Symbols hit by ≥2 channels rank as Hybrid; symbols unique to one keep their original match type. Cuts both structural-noise and semantic-blur in the same query.

Usages (FST)

References stored in an FST (Finite State Transducer) — zero-copy lookup from mmap with prefix search support.

Symbol clusters (vex modules)

vex index groups symbols into clusters of code that call or reference each other (deterministic Leiden-CPM over the call, reference and hierarchy edges; no randomness, so two indexes of the same tree agree). vex modules reads them back:

vex modules                         # clusters of >= 3 symbols, largest first
vex modules --members 5 --sort cohesion --include 'src/**'
vex modules IndexReader             # the cluster of one symbol, with its members
vex modules --format text           # text output (shown below)

Modules — leiden-cpm/1 γ=1/8 · 475 clusters (≥3, showing 3) · 1,469 unclustered · 1,464 not eligible
  #60  src/cli/                     39 symbols  cohesion 0.49  hubs: OutputFormat, print_envelope, default_meta_for
  #23  crates/vex-mcp/src/tools/    38 symbols  cohesion 0.68  hubs: opt_bool, build_command, opt_u64
  #286 src/pattern/matcher/tests.rs 32 symbols  cohesion 0.78  hubs: parse_pattern, find_matches, Segment

(Output above is from this repository at the time of writing; cluster ids are ordinals in the section, not ranks.)

• A cluster's label is the deepest path prefix holding at least 60 % of its members' files. cohesion is internal / (internal + cut) edge weight; the hubs are the three members best connected inside the cluster.
• --include/--exclude/--exclude-tests filter members and hubs (out-of-scope hubs are dropped); a cluster is shown when at least one member is in scope, and its size is the in-scope count (size_at_build keeps the build-time count in JSON).
• Symbol mode reports a per-match status: clustered, unclustered (isolated), not_eligible (headings, modules, markup/config languages) or new_since_build.
• Clusters are computed by vex index and carried, frozen, across vex update. After an update the JSON has stale: true and new_since_build, and text output ends with a ! line; run vex index to recompute. This is separate from _meta.vex.dev/stale, which still means "index older than the working tree".
• --limit must be at least 1; with a SYMBOL it caps the matched symbols (JSON symbols_total reports the uncapped count) and --min-size is ignored. Exit codes: 0 with results, 1 when empty (the reason is in results.empty_reason and on stderr), 2 for a corrupt cluster section. With --workspace, clusters are per repo and --limit applies per repo.

Type-aware refs (--strict)

vex usages --strict <name> reads the v5 reference_edges section written by an LSP-style scope binder. For the languages with a binder (Rust, TypeScript, Python, C#, C++, Go, Java, Kotlin) every ref is resolved at index time against an in-file scope chain plus an import/use graph, then serialised against the global symbol the user actually meant — not just any line that mentions the spelling.

What this changes for the user:

• Identifiers inside comments, doc-strings, string literals, and regex bodies are dropped (this filter is on for everyone, not just --strict).
• A name shadowed by a let / const / fn param resolves to the inner scope, not the outer.
• A use ext::Foo; / import { Foo } from './ext' / from ext import Foo makes a ref to Foo resolve cross-file to whatever defines it in the index. For C++, quoted #include "..." (v1.14+) walks the transitive include graph via BFS to resolve Foo against symbols defined in any reachable header. System headers <vector> / <string> and macro includes (#include MY_HEADER) stay unresolved by design.
• A name imported but never defined in the index stays Unresolved and produces no edge — better than a coincidental match.

Without --strict vex usages still works for every supported language via the legacy refs FST; --strict simply trades recall breadth for precision on the eight binder languages. v3 / v4 indexes predating the binder bail with a "re-run vex index" message.

Structural Patterns (vex pattern)

Match code by shape rather than text. Works on every language vex parses; an indexed prefilter (via the v6 pattern_skeletons section) speeds up candidate selection on the 15 languages that emit skeletons (every language except Bash, Lua, YAML, and TOML, which live-scan).

Syntax:

• $NAME — capture a single identifier or balanced expression. Same name appearing twice enforces a back-reference: record($X, $X) matches record(state, state) and rejects record(state, other).
• $_ — wildcard (matches without capturing).
• $$$ — anonymous ellipsis (matches anything up to the next literal; spans newlines).
• $$$BODY / $$ARGS — named multi-line ellipsis. Functionally identical to $$$ but captures the consumed text under the given name; $$$BODY reads naturally for block bodies, $$ARGS for parameter lists. Back-reference equality also applies.
• && (space-flanked) — AND composition. Both sub-patterns must match in the same file, and shared metavar names must capture the same text in both: struct $S && impl $S matches files that have both shapes for the same $S.
• || (space-flanked) — OR composition (union, deduped by (path, line)). && binds tighter than ||.
• Composition operators only fire at bracket / quote depth 0, so record($X, $X) and f($X && $Y) stay single patterns.

Indexed prefilter: when a v6 index is present, the leading literal keyword of the pattern (fn, struct, class, def, impl, …) is mapped to a tree-sitter node kind, and vex pattern walks only the files whose persisted skeletons contain that kind. Visibility / async / export modifiers in front of the keyword are stripped before the match (pub async fn $F infers function_item correctly). Falls back to live-scan on grammar drift, missing section, or a partial section after vex update — --why reports the exact reason.

Examples:

# Multi-line function body with named captures
vex pattern 'fn $NAME($$ARGS) -> Result<$T, $E> { $$$BODY }' --lang rust

# Both struct and impl for the same type in one file
vex pattern 'struct $S && impl $S' --lang rust

# Interface OR class with the same name
vex pattern 'interface $N || class $N' --lang typescript

# See which mode and what narrowing happened
vex pattern 'fn $N($$$)' --lang rust --why 2>trace.json

Benchmarks

Compared against ast-index v3.31.0 (SQLite + FTS5) and ripgrep 15.1.0.

Methodology: indexing re-measured 2026-08-12 on Apple Silicon (macOS), vex v1.25.5, release build, cold cache, non-semantic index. Search figures are unchanged from the 2026-07-11 / v1.25.1 run (nothing in v1.25.2-v1.25.5 touches the search path) and are the average of 10 runs. Reproduce with ./benches/bench.sh (point VEX_BENCH_LARGE_PROJECTS at your own repos for larger corpora). Numbers are machine-specific — treat the ratios, not the absolutes, as the signal.

Indexing

Project	vex	ast-index	vex size	ast-index size
Small (vex itself, 6.8K symbols)	442 ms	254 ms	4.6 MB	6.7 MB
Medium (ast-index repo, 2.3K symbols)	204 ms	109 ms	1.6 MB	3.4 MB

Honest read: vex indexing is ~1.7-1.9x slower than ast-index — it builds far more at index time (FST + BM25 + persistent call graph + resolved reference edges + a v8 type-hierarchy section + a trigram skip-index + pattern skeletons + symbol clusters (v9)), where ast-index builds a SQLite + FTS5 store. That one-time cost buys the constant-time queries below; the resulting index is still ~1.4-2x smaller on disk (mmap + FST vs SQLite). These measurements are from v1.25.5 (before v9); v9 adds the cluster pass — re-measure pending. The gap was ~2.5-3x when last measured at v1.25.1; v1.25.5 is the main reason it has narrowed — a single-variable A/B against v1.25.4 put its cold-index gain at −34% and −31% on two corpora, from parsing each file once and sharing the tree across all extractors instead of re-parsing it per extractor. Projects indexed with --semantic are slower again (ONNX embedding generation) and produce a larger index.

Search: vex vs ast-index vs ripgrep

Medium project (ast-index repo, 31K lines Rust, avg 10 runs):

Query	vex	ast-index	rg -w	vex vs rg
search	4.7 ms	8.3 ms	9.2 ms	2.0x
SymbolKind	4.6 ms	8.2 ms	8.6 ms	1.9x
parse_file	4.6 ms	7.9 ms	8.7 ms	1.9x
IndexReader	4.7 ms	11.7 ms	8.6 ms	1.8x

Key takeaway: vex search is constant ~4-5 ms (FST O(query_len)) regardless of project size — this is the win the slower index build pays for. The ripgrep comparison is not apples-to-apples: rg scans raw text with no index, so it scales with corpus size (single-digit ms on this 31K-line repo, 100 ms+ on large ones), while vex does a pre-built FST lookup. The durable advantage is amortized and qualitative: vex returns only symbol definitions (precise, token-efficient), while rg returns every text occurrence (noisy, expensive in LLM contexts).

Pattern Matching (vex only)

Medium project (ast-index repo, Rust):

Pattern	Time	Matches
fn $NAME($$$) -> Result	31 ms	50
pub struct $NAME	27 ms	44
fn $NAME($$$)	29 ms	50

ast-index and ripgrep do not support AST pattern matching.

Semantic Search

Illustrative (semantic capability, not a latency benchmark) — queries where structural search returns 0 results but semantic finds relevant symbols:

Query	Structural	Semantic
"parse source code files"	0	19
"database storage"	0	20
"find implementations of an interface"	0	20
"file system directory walker"	0	20
"handle errors and exceptions"	0	20

HNSW vs Brute-Force (semantic vector search)

The latency figures below were measured on an earlier build and not re-run in the v1.25.1 pass — read them as the scaling shape (HNSW stays flat, brute-force grows linearly), not current absolutes.

Semantic search embeds the query via ONNX (~55ms) then searches stored vectors. HNSW (usearch) replaces brute-force O(N) scan with O(log N) approximate nearest neighbor search:

Symbols	Brute-force	HNSW	Speedup
333	~3 ms	~3 ms	1x
11K	~8 ms	~3 ms	2.3x
20K	~11 ms	~3 ms	4x
100K (projected)	~55 ms	~3 ms	~18x

HNSW stays constant ~3ms regardless of index size. Brute-force grows linearly. Total semantic search latency is dominated by ONNX embedding (~55ms), so end-to-end speedup is modest for small codebases but critical at scale.

Mode	Latency
Structural only	~4 ms
Hybrid (structural + semantic)	~58 ms (HNSW) / ~66 ms (brute-force)

LLM Token Efficiency

When an AI agent searches code, the output goes directly into the context window. Grep-based tools return every text occurrence — including comments, strings, variable usage, and matches in minified files — consuming tokens without adding signal.

vex returns only symbol definitions in a compact one-line format, drastically reducing token consumption:

	vex compact	rg (grep)	Reduction
7 symbol lookups (typical)	~220 tokens	~1,300 tokens	6x
Queries hitting minified JS/CSS	~270 tokens	~58,700 tokens	217x

Example — searching for a class name on a large project:

# rg: 20 matches across imports, usage sites, comments, tests (2,045 chars)
$ rg -w "PreAggregatedConfig" .
./models.py:3602:class PreAggregatedConfig(models.Model):
./models.py:3610:    pre_aggregated_config = PreAggregatedConfig.objects.get(...)
./serializers.py:48:from .models import PreAggregatedConfig
./tests.py:12:    config = PreAggregatedConfig(...)
... (16 more lines)

# vex: 1 definition (93 chars)
$ vex search "PreAggregatedConfig" --format compact
C PreAggregatedConfig models.py:3602 class PreAggregatedConfig(models.Model):

For an agent making 10-20 code lookups per task, vex saves 5,000-20,000 tokens per session compared to grep — reducing cost and leaving more context window for reasoning.

Supported Languages

19 languages indexed via tree-sitter. The capability columns:

• Binder — does vex usages --strict resolve refs through an LSP-style scope chain (Phase 11.1)? cross-file includes use / import resolution; in-file resolves within a file but treats imports as unresolved. The remaining languages fall back to the line-based scanner used by plain vex usages.
• Patterns — does vex pattern get the v6 indexed prefilter (Phase 11.4)? indexed means a persisted skeleton section narrows candidate files at query time; live-scan means tree-sitter walks every lang-matching file on each query. All 19 languages work with vex pattern syntax ($NAME, $$$BODY, && / ||); the prefilter just speeds up discovery for the 15 languages that emit a skeleton section (every language except Bash, Lua, YAML, and TOML).

Language	Extensions	Symbols	Imports	Binder	Patterns
Rust	.rs	functions, structs, enums, traits, impls, types, constants	use declarations	cross-file	indexed
TypeScript/JS	.ts, .tsx, .js, .jsx, .mjs, .cjs	classes, interfaces, enums, functions, arrows, type aliases	import	cross-file	indexed
Python	.py	classes, functions (incl. async, decorated)	import, from..import	cross-file	indexed
C#	.cs	classes, interfaces, structs, enums, methods, properties	using	cross-file	indexed
C/C++	.cpp, .cc, .cxx, .hpp, .hxx, .h (.c files not indexed, only .h via C++)	classes, structs, functions, methods, templates, enums	#include	cross-file (v1.14 BFS over quoted #include "..."; class methods still in-file)	indexed
Go	.go	functions, methods, structs, interfaces	import	cross-file	indexed
Java	.java	classes, interfaces, enums, methods, constructors	import	cross-file	indexed
Kotlin	.kt, .kts	classes, interfaces, objects, functions, properties	import	cross-file	indexed
Ruby	.rb	classes, modules, methods	—	—	indexed
Swift	.swift	classes, structs, enums, actors, protocols, functions	import	—	indexed
PHP	.php, .phtml	classes, interfaces, traits, methods, functions	use, require	—	indexed
SQL	.sql	tables, views, functions, triggers, indexes, schemas, types, sequences	ALTER TABLE refs	—	indexed
Markdown	.md, .markdown	headings (section structure)	—	—	indexed
Bash	.sh, .bash	functions	—	—	live-scan
Lua	.lua	functions, local functions, tables	require	—	live-scan
CSS	.css	rules, selectors, @keyframes	—	—	indexed
HTML	.html, .htm	custom elements (hyphenated tag names)	—	—	indexed
YAML	.yaml, .yml	top-level keys	—	—	live-scan
TOML	.toml	bare keys, dotted keys, tables	—	—	live-scan

See docs/SUPPORTED_LANGUAGES.md for grammar versions, ABI level, and the runbook for adding a language or upgrading a grammar. Adding a language to the indexed-Patterns tier is one allowlist edit in src/pattern/skeleton/kinds.rs — the Phase 11.4 follow-up promotion (Go → Java → Kotlin → C# → C++ → Swift → PHP → Ruby, plus SQL / Markdown / CSS / HTML) is complete; only Bash, Lua, YAML, and TOML remain on live-scan.

Index Location

macOS:     ~/Library/Caches/vex/<hash>/index.vex
Linux:     $XDG_CACHE_HOME/vex/<hash>/index.vex (fallback: ~/.cache/vex/<hash>/index.vex)
Windows:   %LOCALAPPDATA%\vex\<hash>\index.vex   (fallback: %USERPROFILE%\AppData\Local\vex\<hash>\index.vex)

Each project gets its own index based on a hash of the canonical project root path (xxh3). Overrides:

• --cache-dir <path> — point vex at a custom cache directory
• $VEX_CACHE_DIR — environment variable (lower precedence than --cache-dir)
• cache_dir in .vex.toml — configuration file (lowest precedence)

Known limitations

vex is a static-analysis tool — some real call sites and references are invisible by construction. The headline gaps:

• vex callers outside function scope — Module-level expressions are reported via synthetic <module:path> callers (Phase 14.1). Python + Java function/method decorators (Phase 14.2), Kotlin annotations + C# method/constructor attributes (Phase 14.2.2), and TypeScript method decorators + Rust outer attributes on fns/methods (Phase 14.2.1) emit forward edges. Remaining gap: class-level decorators (Phase 14.6); Rust #[derive(...)] is intentionally filtered.
• vex usages quality depends on language. Rust / TypeScript / Python / C# / C++ get --strict (binder-resolved refs from the v5 reference_edges section, Phase 11.1). Other languages use a line-based identifier scan with a higher false-positive rate.
• Dynamic dispatch is invisible. String-resolved factories (uvicorn.run("main:app")), task queues (celery_task.delay()), reflection (getattr(obj, name)()) — none of these produce edges.
• Workaround: vex grep '\bname\b' is the exhaustive textual fallback. Slower (~50 ms) but never misses a hit.

See docs/LIMITATIONS.md for the full coverage matrix, repros, and recommendations per query type.

Troubleshooting

Surfacing internal warnings

Vex emits structured logs via the tracing crate at parse/store boundaries — failed grammar loads, mmap reopens, manifest mismatches, and so on. By default RUST_LOG is unset, so only the most critical diagnostics make it to stderr.

When a search returns surprising results or an index command behaves oddly, raise the log level:

RUST_LOG=vex=warn vex search Foo
RUST_LOG=vex=info vex index   # noisier — file-level progress

For what the search engine actually did (per-channel hit counts, fuzzy fallback engagement, applied filters), use the structured trace instead:

vex search Foo --why 2>trace.json   # trace lands on stderr as JSON

See docs/MCP-SCHEMA.md for the --why / why: true JSON shape.

Integration

Claude Code (CLI Integration)

The recommended way to integrate vex with Claude Code is via CLAUDE.md rules (see below). Vex runs as a CLI tool — Claude Code calls it directly via Bash, no MCP server needed.

Setup:

# Install vex
brew tap tenatarika/tap && brew install vex

# In your project
cd /path/to/project
vex init              # create .vex.toml
vex index             # build index (add --semantic for meaning-based search;
                      # add --history for `vex history <Symbol>` archaeology queries — v1.15.0/v1.16.0)

Then add .vex.toml config for auto-update so Claude always searches a fresh index:

# .vex.toml
auto_update = true
# format = "compact"   # already the default since v1.10.1 — set "text" if you'd rather see verbose output

Multi-repo (v1.22.0): if Claude Code is working across several repos at once, drop a .vex-workspace.toml at the common parent and tell Claude to add --workspace to its vex calls — e.g. vex usages Config --strict --workspace to trace a symbol's references across every repo, or vex check Foo --workspace to see which repos define it. Results come back grouped by repo. See Multi-repo workspaces.

Claude Code (MCP Server)

Alternatively, vex includes an MCP server (vex-mcp) that exposes all commands as MCP tools. Note: Homebrew installs only vex (not vex-mcp). Since v1.11.2 a prebuilt vex-mcp binary ships in every release alongside vex for the three triples the build matrix covers: aarch64-apple-darwin (macOS Apple Silicon), x86_64-unknown-linux-gnu (Linux), and x86_64-pc-windows-msvc (Windows). Intel-Mac and other triples still require the source build below.

Easiest setup (v1.15.0+):

vex mcp install --agent claude-code

This runs claude mcp add --scope user --transport stdio vex --env VEX_ROOT=<root> -- <vex-mcp> for you (v1.27.1+). If the claude CLI is not on PATH, it prints that command instead and writes nothing. Releases before v1.27.1 wrote ~/.claude/claude_desktop_config.json, which Claude Code does not read; re-run the command after upgrading.

Manual setup:

# 1. Download the prebuilt for your platform from
#    https://github.com/tenatarika/vex/releases/latest
#    e.g. vex-mcp-aarch64-apple-darwin.tar.gz / vex-mcp-x86_64-pc-windows-msvc.tar.gz
# 2. Extract and put the binary on PATH (or remember the full path).

# Source build (if you prefer or are on an unsupported triple)
cargo build --release -p vex-search-mcp

# Register with Claude Code (user scope; Claude Code keeps it in ~/.claude.json)
claude mcp add --scope user --transport stdio vex \
  --env VEX_ROOT=/path/to/your/project --env VEX_DEVICE=auto \
  -- /path/to/vex-mcp

# Or project scope: commit a .mcp.json at the project root
# (see integrations/claude-code/mcp.json)

VEX_DEVICE (v1.16.0) picks the GPU execution provider when the binary was built with gpu-cuda / gpu-directml / gpu-coreml — relevant when an MCP-driven index / update call rebuilds semantic embeddings on a large repo (51× CUDA / 29× DirectML over CPU on MiniLM-L6). auto is safe on CPU-only builds (degrades silently). Run vex gpu once to confirm the EP actually engages.

MCP Tools (28):

• search — 3-way hybrid (structural + BM25 + semantic); accepts filter / include / exclude / kind / context_path / no_bm25 / --why / metadata filters / diff-scope (since / since_branched / changed_only)
• find_symbol — exact name lookup
• find_similar — semantic search by free-form description
• similar — nearest neighbors of an existing symbol (explain adds Jaccard + diff); diff-scope
• duplicates — near-duplicate symbol pairs (explain shows what differs); diff-scope
• show — extract symbol body from source; Phase 13.3 truncation flags (signature_only / head / no_body / collapsed, mutually exclusive)
• outline — file structure
• usages — find all references to a symbol; filter_path / strict / why
• impact — delete-safety blast radius (verdict + per-channel evidence); depth / exclude_docs
• grep — regex content search
• pattern — AST pattern matching with metavar back-references; diff-scope; --why
• implementations — find types extending a base class/trait/interface (incl. generics); diff-scope
• subtypes — transitive-down closure over extends/implements edges (direct children, grandchildren, …), depth-labelled; index-only (no live-walk fallback); depth / diff-scope
• modules — de-facto modules: clusters of symbols that call/reference each other (v9 index, computed on full vex index); list clusters (label, size, cohesion, hubs) or pass symbol for its cluster; limit / min_size / members / sort / scope / workspace; empty result + empty_reason on older indexes or --no-clusters
• callers / callees — direct callgraph navigation (fast path via persistent index); diff-scope
• paths — enumerate caller chains between two functions
• reachable — transitive callers of a target
• tests_for — test functions that transitively cover a target (framework-labelled)
• diff — symbol-level diff between a git revision and the working tree
• check — fast symbol existence check
• bundle — unified multi-source bundle (mode: symbol | pr-impact | project), Phase 13 envelope
• eval — ranking-evaluation harness (bench / min_ndcg), MCP defaults json: true so agents get a structured EvalReport
• capabilities — machine-readable capability matrix (protocol_version, signals, bundle_modes, history_diff (v1.16.0), symbol_clusters, etc.)
• index / update — build/rebuild index; v1.16.0 adds gpu: bool / device: cpu|auto|cuda|directml|coreml args (GPU-enabled builds only) so an agent can opt into GPU semantic embedding per-call without touching env or config
• status — index statistics (now includes gpu_support / default_device (v1.16.0))
• history — historical versions of a symbol across commits (MCP tool since v1.20.0, D5); depth / limit / since / until / author / kind / diff / exact_presence

Note: vex history and vex tests-for were promoted to first-class MCP tools in v1.20.0 (D5); earlier docs that called history "CLI-only" are stale. Both emit the same --format json envelope as every other vex command.

Multi-repo (v1.22.0): eleven tools — search, grep, check, usages, impact, callers, callees, reachable, modules, index, update — take a workspace: boolean arg that fans the call across every .vex-workspace.toml member, returning the grouped {workspace, repos:[...]} payload under structuredContent.results. Point project_root at or above the .vex-workspace.toml. find_symbol is excluded (use check/search); why is ignored in workspace mode. See docs/MULTIREPO-PHASE8-mcp.md.

MCP ↔ CLI parity (v1.10): the schemas now mirror the CLI surface for every path-aware tool. Glob filters (include / exclude), substring filter, kind boost, context_path proximity hint, no_bm25, Phase 13.3 truncation, diff-scope, and no_stale_check are exposed everywhere the CLI accepts them — agents no longer need to drop to bash for "Rust files under crates/api/ since main"-style scoping.

The schemas follow a canonical vocabulary (query / symbol / symbols / path / pattern / filter / include / exclude); pre-v1.7 aliases (name, file, names, etc.) still work and emit _meta.deprecated_args: [...] in the JSON-RPC response. Malformed JSON-RPC input now returns the spec-compliant -32700 Parse error response (v1.9.2 fix) with a 512-codepoint echo of the offending line in the data field; broken-pipe / EOF on stdin cleanly shuts down the server instead of dropping in-flight tool calls. See docs/MCP-SCHEMA.md.

For other MCP-compatible clients (Cursor, Codex CLI, Windsurf, Cline, Continue.dev, Zed), see Other MCP Clients below — same vex-mcp binary, different config files.

Other MCP Clients

The same vex-mcp binary works with any MCP-compatible client. The binary install is identical to the Claude Code section above; only the per-client config file location and format differ.

One-line setup (v1.15.0+):

vex mcp install --agent cursor       # or any of: claude-code, codex-cli, windsurf, cline, continue, zed
vex mcp install --agent all          # fan out across every supported agent
vex mcp install --agent cursor --dry-run   # preview the post-merge config without writing

For file-based agents, vex mcp install reads your existing agent config, merges a single vex server entry without disturbing siblings, and writes back atomically. For Claude Code it runs claude mcp add instead of editing a file. Idempotent — re-running on a matching entry is a no-op skip (--force overrides). vex mcp uninstall --agent <X> removes the entry; vex mcp list enumerates current entries per agent. The config files documented below for the other agents are exactly what vex mcp install writes — keep integrations/ handy for manual edits, agents the auto-installer doesn't know yet, or anything more exotic than the default shape.

Copy-pasteable snippets for the most common ones live under integrations/:

Agent	Snippet	Target file on disk
Claude Code	integrations/claude-code/ (mcp.json for project scope)	registered via claude mcp add (user scope) or <project>/.mcp.json
Cursor	integrations/cursor/mcp.json	~/.cursor/mcp.json or <project>/.cursor/mcp.json
Codex CLI (OpenAI)	integrations/codex-cli/config.toml	~/.codex/config.toml or <project>/.codex/config.toml
Windsurf (Codeium)	integrations/windsurf/mcp_config.json	~/.codeium/windsurf/mcp_config.json
Cline (CLI)	integrations/cline/mcp.json	~/.cline/mcp.json (VS Code extension: configure via panel UI)
Continue.dev	integrations/continue/vex.yaml	./.continue/mcpServers/vex.yaml (project-scoped)
Zed	integrations/zed/settings.json	~/.config/zed/settings.json

Per-agent caveats (auto-approve flags, timeout overrides, agent-mode requirements) are documented in integrations/README.md.

MCP Registry (from v1.27.2): vex is listed in the official MCP Registry as io.github.tenatarika/vex. Each release attaches one MCP Bundle per platform (vex-mcp-<target>.mcpb, macOS arm64 / Linux x86_64 / Windows x86_64) that holds both vex-mcp and vex; an MCPB-capable client asks for the project root once and needs nothing else on PATH. Bundle installs are updated by the client, not by vex self-update (which refuses to run inside a bundle).

Glama: also listed in the Glama MCP directory, which builds the server and grades its tools.

Agent Recipes & Workflows

Once vex-mcp is wired into your agent, the next question is what to ask the agent so it picks the right tools in the right order. docs/COOKBOOK.md is a recipe collection for the common chains — code archaeology, cross-file refactor with usages --strict verification, PR-impact analysis via bundle(mode="pr-impact"), dead-code & duplicate cleanup, and multi-repo orchestration. Each recipe shows the tool sequence, the why of the ordering, and a phrase that reliably triggers the chain in agent prompts.

Documentation & Integration:

• Full vex documentation and API reference: https://context7.com/tenatarika/vex (on Context7)
• Agent skill reference: .claude/skills/vex/SKILL.md (included in the project)

Shell Integration
